China Wire Rope Sling manufacturer

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope

Product Details:
Place of Origin: Made in China
Brand Name: SOLAR
Certification: ABS(USA), BV(France), CCS(China), DNV(Norway), GL(Germany), KR(Korea), LR(U. K. ), NK(Japan), RINA(Italy), RS(Russia) & Works Certificate.
Model Number: Glva/Bright Wire Rope
Payment & Shipping Terms:
Minimum Order Quantity: 1 meter
Price: Negotiable
Packaging Details: Pallet, Reels
Delivery Time: within 7 days
Payment Terms: L/C, D/P, T/T
Supply Ability: Depends on Order

Detail Information

Product Name: 8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Glva/Bright Wire Rope Wire Rope Structure: 8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC
Standard: GB/DIN/BS/JIS/ASTM/AISI/API/ISO Technique: Galvanized/Ungalvanized/Bright
Diameter: 20mm~200mm, On Your Request Length: Depends On Order, 1~1000 Meter
Tensile Strength: 1570Mpa 1670Mpa 1770Mpa 1870Mpa~1960Mpa PS IPS EIPS Core Type: Fiber Core/IWRC
Packing: Reel/Pallet Application: Mine Lifting, High-furnace Hoist, Lifting, Marine,offshore,Oil Drilling, Shipping, Construction, Mining
Company Type: Manufacturer, Supplier, Expoter Port Of Origin: Shanghai China
HS Code: 73121000
High Light:

8x25Fi+IWRC

,

8x25Fi+FC

Product Description

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Marine Steel Wire Rope

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope



Rope Type:    8x25Fi 8x26WS

Rope Construction: 8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC

Application:

1. It is used in heavy rigging,heavy-duty hoisting machinery,salvage,etc.

2. Steel wire ropes with diameters from 20mm to 200mm

3. 4:1/5:1/6:1 safety factors





EIPS = 1960Mpa (Extra Improved Plow Steel)

EEIPS= 2160Mpa

IPS=1870Mpa

PS=1770Mpa



FC = Fiber Core

IWRC = Independent Wire Rope Core





Environmental Considerations

IWRC must not be used at temperatures above 400°F.

FC must not be used at temperatures above 180°F.

Fiber core ropes should not be subjected to degreasing solvents



8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 0





Nominal Diameter Approx.Weight Nominal Tensile Strength of Rope (MPa)
1570 1670 1770 1870 1960
Minimun Breaking Load of Rope
D FC IWR/IWS FC IWR/IWS FC IWR/IWS FC IWR/IWS FC IWR/IWS FC IWR/IWS
mm kg/100m (KN)

20 142 166 158 187 168 198 178 210 188 222 197 233
22 172 201 191 226 203 240 215 254 227 269 238 282
24 205 239 227 269 241 286 256 303 270 320 283 335
26 241 281 266 315 283 335 300 355 317 375 333 394
28 279 325 309 366 329 389 348 412 368 435 386 456
30 320 374 355 420 377 446 400 473 422 500 443 524
32 365 425 404 477 429 508 455 538 481 569 504 596
34 412 480 456 539 485 573 514 608 543 642 569 673
36 461 538 511 604 543 643 576 681 608 720 638 754
38 514 599 569 673 605 716 642 759 678 802 710 841
40 570 664 631 746 671 794 711 841 751 889 787 931
42 628 732 695 823 739 875 784 927 828 980 868 1030
44 689 803 763 903 812 960 860 1020 909 1080 952 1130
46 753 878 834 987 887 1050 940 1110 993 1180 1040 1230
48 820 956 908 1070 966 1140 1020 1210 1080 1280 1130 1340
50 890 1040 985 1170 1050 1240 1110 1310 1170 1390 1230 1460
52 963 1120 1070 1260 1130 1340 1200 1420 1270 1500 1330 1570
54 1040 1210 1150 1360 1220 1450 1300 1530 1370 1620 1430 1700
56 1120 1300 1240 1460 1310 1560 1390 1650 1470 1740 1540 1830
58 1200 1400 1330 1570 1410 1670 1490 1770 1580 1870 1650 1960
60 1280 1490 1420 1680 1510 1790 1600 1890 1690 2000 1770 2100
62 1370 1600 1510 1790 1610 1910 1710 2020 1800 2130 1890 2240
64 1460 1700 1610 1910 1720 2030 1820 2150 1920 2270 2020 2380
66 1550 1810 1720 2030 1830 2160 1940 2290 2040 2420 2140 2540
68 1650 1920 1820 2160 1940 2290 2050 2430 2170 2570 2270 2690
70 1740 2030 1930 2280 2050 2430 2180 2580 2300 2720 2410 2850
72 1850 2150 2040 2420 2170 2570 2300 2730 2430 2880 2550 3020
74 1950 2270 2160 2550 2300 2720 2430 2880 2570 3040 2690 3190
76 2060 2400 2280 2690 2420 2860 2570 3040 2710 3210 2840 3360
78 2170 2520 2400 2840 2550 3020 2700 3200 2860 3380 2990 3540
80 2280 2660 2520 2980 2680 3170 2840 3360 3000 3550 3150 3730
82 2390 2790 2650 3140 2820 3340 2990 3530 3160 3730 3310 3910
84 2510 2930 2780 3290 2960 3500 3130 3710 3310 3920 3470 4110
86 2630 3070 2910 3450 3100 3670 3290 3890 3470 4110 3640 4310
88 2760 3210 3050 3610 3250 3840 3440 4070 3630 4300 3810 4510
90 2880 3360 3190 3780 3400 4020 3600 4260 3800 4500 3980 4720
92 3010 3510 3340 3950 3550 4200 3760 4450 3970 4700 4160 4930
94 3150 3670 3480 4120 3700 4380 3930 4640 4150 4910 4350 5140
96 3280 3820 3630 4300 3860 4570 4090 4840 4330 5120 4530 5360
98 3420 3990 3780 4480 4030 4760 4270 5050 4510 5330 4720 5590
100 3560 4150 3940 4660 4190 4960 4440 5260 4690 5550 4920 5820
106 4000 4660 4430 5240 4710 5570 4990 5910 5270 6240 5530 6540
110 4310 5020 4770 5640 5070 6000 5380 6360 5680 6720 5950 7040



8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 1

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 2











8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 3



8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 4










We can also provide Steel Wire Rope Slings

HOW TO ORDER WIRE ROPE SLINGS

  • Define rope diameter. 1-1/4" or 24mm in example
  • Rope Structure. 6X37 IWRC EIPS construction for example.
  • laid RHLL(Z) or LHLL(S) for cable laid rope.
  • Sling Length (length could be 0.5~1000meter, feet and meter both OK)
  • Terminations, end with soft eye or Hard eye (Thimble Eye)

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 5

8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 6



8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 7





8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 8



8x25Fi+IWRC 8x25Fi+FC 8x26WS+IWRC 8x26WS+FC Steel Wire Rope 9
