Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble

Product Details:
Place of Origin: Made in China
Brand Name: SOLAR
Certification: Mill Certificate
Model Number: 8mm~85mm
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Pallet/Plastic Bags/Wooden Box
Delivery Time: 0-60 days mainly according What item and how many quantities
Payment Terms: L/C, T/T
Supply Ability: 100 pcs a week

Detail Information

Material: Cast Steel Wire Rope Structure: 6x36WS/35Wx7/6strands/8strands/Non-rotating Anti-twist
Surface: Galvanized/Painted Size: For 8mm~85mm Wire Rope
Packing: Pallet/Plastic Bags/Wooden Box Safe Working Load (SWL): 1Ton~180Ton
Standard: Meet The Standard Of EN818-2, ASTM, ISO, American Standard, European Standard Safety Factor: 1:4 Normally, 1:6
Port Of Origin: Shanghai China

Product Description

DIN 3091 Solid Thimble for Wire Rope Sling



using together with wire rope for make a heavy duty wire rope sling



  • Galvanised / Self Coloured
  • Available with Standard Hole or Machined Hole
  • Marked With Nominal Size

For pricing, delivery options and general enquiries, please Contact Us at Sharon.Wang@solarswr.com





Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble 0





DIN 3091 重型套环 DIN 3091 HEAVY MALLEABLE CAST RING
SIZE(mm) d L C d1 b

8 9 56 40 14 15
10 11 70 50 18 17.5
12 13 84 60 21 20
14 16 98 70 25 23.5
16 18 110 80 28 26
18 20 130 90 31 28.5
20 22 140 100 35 31
22 24 150 110 38 33.5
24 26 170 120 41 36
26 29 180 130 44 39.5
28 31 200 140 47 42
32 35 220 160 53 47
36 40 250 180 59 53
40 44 280 200 65 58
44 48 310 220 70 63
48 53 340 240 76 69
52 57 360 260 81 74
56 62 390 280 86 80
64 70 450 320 95 90
72 79 500 360 104 101





Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble 1





Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble 2



Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble 3Rope Wire Fitting Marked With Nominal Size DIN 3091 Solid Thimble 4
